ASL-900
Aslan machinery
8438500000
cattle tripe washing and cleaning machine
Tripe Washing machine is mainly used for pigs, cattle, sheep tripe cleaning processes. Its body made by high quality stainless steel . Machine is easy operation, low noise, easy to clean and so on. It Can effectively improve work efficiency, reduce labor intensity. Suitable For medium to large slaughterhouse.
Tripe washing machine construction :
Structure and working principle (structure diagram attached at the end of this file)
Machine Structure:machine include the inlet pipe, sewage, spherical cavity, rotating disk, spindle, spindle sleeve, roller bearings are set, belts, pulleys, motors, cabinet parts. How it works: machine driven by the motor shaft through the conveyor, rotating disk running in high-speed rotation, meanwhile, pigs (cattle, sheep) tripe rotating disk under the centrifugal force on the ball were thrown to the edge of the cavity. Tripe turn back after a collision turntable with the the cavity wall , and then tripe friction with the round sticks on rotate round disc. So pigs (cattle, sheep) tripe rubbing repeatedly turned aside to complete cleaning.
machine detail as follow:
| model | capacity | power | machine size | machine weight | material |
| ASL-700 | 150KG/H | 5.5KW | 1500*950*1300mm | 500KG | SUS304# |
| ASL-900 | 250KG/H | 5.5KW | 1200*710*865mm | 300KG | SUS304# |
Cattle tripe washing machine photo:
