ASL-ZQH-CHERRY
ASLAN MACHINERY
8438600000
automatic fresh cherry core pitting removing machine
this is a professional cherry core removing machine use to removing cherry core , suitable for cherry , olive , dates , jujube and so on berry fruit .
Working principle: raw material transports it to the punching station with a chain. Under the action of the upper die, the wedge-shaped centralizing die completes automatic axis positioning and clamping. Tightly, the jujube core is punched down by the punching needle, and then the punching needle and the upper die go up and return, and the lower die is separated by the elastic force, and the jujube flesh is loosened. When the chain turns to the blanking position, the blanking is completed.
cherry core pitting machine parameter:
| Model | ASL-ZQH-cherry |
| capacity | 200kg/h |
| voltage | 380v 50hz 3 phases |
| motor | 1.1kw |
| depit rate | >95% |
| machine size | 1200*1000*1150mm |
| machine weight | 350kg |
| machine function | remove fruit core |
cherry core removing machine photos:
